1PCS LED Digital Sensor Ampere Meter DC 0-600V 10A 0.39 Inch

Current ProbesLED Digital Sensor Voltage Ampere Panel Ampere Meter DC 0-600V 10A LED Digital DC Voltmeter Ampere Meter 0.39 Inch1. Current transformer is included and no need to purchase separately.2. Please try not to install the meter and current transformer near high temperature and strong magnetic fieldand large , otherwise the accuracy will be affected.3. In order to obtain higher accuracy measurement, it is recommended to "warm up for 5 minutes" before measurement.4. Since the float charge voltage of a 24V battery may exceed 30V after being fully charged, it is not recommended to use it directly.5. When choosing a range, the larger the better. The larger the range, the greater the error. It is recommendedIt is 1.5 times or 2 times the actual test value.Power supply voltage: DC4-30V (Note: The input voltage cannot exceed 30V, otherwise it will burn out.)<;30 mATest voltage: DC0-600VTest current: DC0-10ADisplay Type: 0.39'' LED with red and green fontsMeasurement rate: 500mS/timeMeasurement accuracy: 1% (±2 digits)CT line length: 150mmTerminal wire length: 150mmSize: 70*40*30mmMounting hole: 68*38mmSize: 70*40*30mmOperating temperature: -10 to +50 degreesPower supply voltage: DC4-30VAccuracy level: 1% +/- 2 digitsModel: YB4835HVAInstallation size: 68*38mmMeasuring speed: about 2 times/SDisplay type: 0.39'' LED, red and green digitalTest current: DC0-10ATest voltage: DC0-600VFeatures: Three lines
