Amana Tool - 45798 Carbide Tipped Double Edge Folding V-Groove 135 Deg x 0.080" Tip Wi
Product details
| Management number | 216504227 | Release Date | 2026/04/19 | List Price | $37.14 | Model Number | 216504227 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Designed for shaping aluminum composite (sandwich) materials (ACM) with 135° angle v-grooves with Flat bottoms. Routing v-shaped grooves, whereby the aluminum cover and a part of the polyethylene core is removed, allows Folding/creasing the remaining material by hand. Ideal for wall panel fabrication., ACM is widely used for cladding many diverse exterior and interior applications such as office buildings, hospitals, convention centers, airports, and hotels. The long lasting durability of the material makes it an excellent choice for buildings, signage, displays, etc., #45798, diameter (D) 3/4, angle (a°) 135°, cutting Height (B) 1/2, shank (D) 1/4, overall length (L) 2-1/4, B1 9/64, Type carbide Tipped V-Groove, Max RPM 28, 000, flutes 2, D1 0.080", A1° 22.5°, carbide Tipped double edge Folding V-Groove 135 deg X 0.080 inch tip width x 3/4 dia x 1/2 x 1/4 inch Shank
- Diameter (D) 3/4
- Angle (a°) 135°
- Cutting height (B) 1/2
- Shank (D) 1/4
- Overall length (L) 2-1/4
| Size | 1/2 CH x 3/4 D x 1/4 Inch SHK |
|---|---|
| Finish | Aluminum |
| Material | Carbide |
| Item Weight | 0.002 ounces |
| Part Number | 45798 |
| Manufacturer | Amana Tool |
| Item model number | 45798 |
| Batteries Included | No |
| Batteries Required | No |
| Package Dimensions | 4.49 x 1.89 x 0.43 inches |
| Included Components | 1 Amana Branded Tool |
| Item Package Quantity | 1 |
