Ebike Headlight and Tail Light Sets, LED Night Spotlight Cycling Modification Parts, 48V/36V Front Rear Warning Lights Kit with E-Bike Headlight Turn Signal Rear Light, 12V-72V Switch 24-48V
Product details
| Management number | 210331942 | Release Date | 2026/04/02 | List Price | $12.80 | Model Number | 210331942 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Description: Name: Electric Bicycle SetFront Light Material: PC ABS Product Size: Approx65mmx52mmx45mm Light Source: LED Light Color: Black Lighting Distance: 40-60meters at nightRear Light Model: D-05DC Size: 147 x 44 x 42mm Applicable voltage: 48V / 36V Rear light current: 48V/13mA, 36V/10mA Material: ABS Power: 0.5W Function: rear light, brake light, turn signal Light brightness: 15LM Outlet: four-core wire Waterproof grade: IPX4 Installation location: the rear of the frameSwitch: Voltage: 12V-72V Cable length: 1500mm/59.06in Weight: 38.4g Operating temperature: -20°C~60°C Material: PP TPR Wire pulling force:> 130N Core: 8 Pins Current: 0.5A/12V DC Waterproof: IPX4 Red button: Bicycle light Green button: Bicycle Horn Installation diameter: φ22.2mm Function: Control horn and light ON/OFFhint: 1. This product is not suitable for Bafang or TSDZ mid-mounted motors. 2. This product needs to be connected to the same battery as the controller, otherwise the braking function cannot be activated. 3. Connecting to the brake requires the controller to be a low-speed brake.Packing list: 1 x Electric Bicycle Front Rear Warning Lights Set Note: Different displays may cause the color of the item in the picture a little different from the real thing. Manual measuring,please allow 1~3mm error,thank you.
- 💗【Running Lights】When the switch of running lights is turned on, the running lights of headlights and taillights will light up.
- 💗【Brake Light】When the brake signal line is normally connected with the controller's brake low pressure signal, the brake light will light up when braking.
- 💗【Turn Signal Light】When the turn switch in the specified direction is toggled, the turn signal in the corresponding direction starts to work and flashes at a 800ms each time.
- 💗【Horn】Press down the button to activate.
- 💗【Easy to Install】Don't need to find a professional maintenance worker, you can quickly complete the replacement yourself. Super easy, fast and cost-efficient.
| Color | 24-48v |
|---|---|
| Brand Name | Gaderth |
| Item Weight | 38.4 Grams |
| Manufacturer | Gaderth |
| Power Source | Battery Powered |
| Material Type | Acrylonitrile Butadiene Styrene, Polycarbonate, Polypropylene |
| Mounting Type | Handlebar Mount |
| Auto Part Position | Front |
| Number of settings | 1 |
| Light Output Maximum | 15 Lumens |
| Water Resistance Level | Waterproof |
| Manufacturer Part Number | JVMU3MB6fJjIzK_ceV45Dw8cm |
| International Protection Rating | IPX4 |
