Jake Sales #17 x 14 Construction Lag Screw - Torx/Star Drive Heavy Duty Structural Lag Screw - Exterior Coated - ACQ Compatible - Modified Truss Washer Head. 1 x 25 Count Box - 25 Screws
Product details
| Management number | 211255869 | Release Date | 2026/04/04 | List Price | $29.96 | Model Number | 211255869 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Jake Sales #17 x 14" Construction Lag Screw - Torx/Star Drive Heavy Duty Structural Lag Screw - Exterior Coated - ACQ Compatible - Modified Truss Washer Head. 1 x 25 COUNT BOX - 25 Screws-Screw Dimensions - ~5/16" Thread Diameter - 11/16" Head Diameter - Length 14"-Manufactured from High Quality Heat Treated Steel, Triple Coated, ACQ Treated Lumber Compatible-Corrosion Resistant Lag Screws Passed the 1200 Hour Salt Spray Test Without Coating Failures-Type 17 Notched Extra Sharp Point for Quick Starts without "Walking", Reduces Need for Pre-Drilling-Construction Lag Screws Far Exceed Standard Lag Bolts in Shear Compression Forces-Deep, Wide, Sharp Screw Threads for Maximum Holding Power, Excellent for Hard and Soft Wood-Knurled Screw Shoulder Lowers Drill Torque Requirements, High Quality Threads Cut Clean and Easy-Deep Torx/Star Drive Head Reduce "Cam-out" While Driving Screw-Great Screw for Decking, Fencing, Roofing, Framing, Timber Frame or Post, and Beam Screw Engineering Specs:Average Shear Strength of #17 Shank --- 1,367 lbfAverage Pull-Out Strength ---- 4" - 1065 lbf (Thread Length)(Screw Pull-Out is Calculated by Screws installed in the Side Grain of a Main Member - Southern Pine)***Insert_Text1***
- Screw Dimensions - ~5/16" Thread Diameter - 11/16" Head Diameter - Length 14"
- Manufactured from High Quality Heat Treated Steel, Triple Coated, ACQ Treated Lumber Compatible
- Corrosion Resistant Lag Screws Passed the 1200 Hour Salt Spray Test Without Coating Failures
- Type 17 Notched Extra Sharp Point for Quick Starts without "Walking", Reduces Need for Pre-Drilling
- Construction Lag Screws Far Exceed Standard Lag Bolts in Shear Compression Forces
| UPC | 840129212744 |
|---|---|
| Brand | Jake Sales |
| Color | BRONZE |
| Model | 17-14-CONSTRUCTION-LAG-SCREWS-CTX-25 |
| Head Type | Truss |
| Size Name | #17 x 14" - 25 SCREW COUNT |
| Metal Type | Alloy Steel |
| Unit Count | 25.0 Count |
| Part Number | 17-14-CONSTRUCTION-LAG-SCREWS-25 |
| Thread Size | 17 |
| Drive System | Torx |
| Finish Types | Bronze Coated |
| Grade Rating | Greater Than Grade 8 |
| Manufacturer | Jake Sales |
| Thread Style | Right Hand |
| Fastener Size | 17 (3/8") |
| Fastener Type | Deck Screws |
| Item Diameter | 9.53 Millimeters |
| Material Type | Exterior Coated Steel |
| Exterior Finish | Coated Screw |
| Item Dimensions | 14 x 0.69 x 0.69 inches |
| Thread Coverage | Partially Threaded |
| Number of Pieces | 1 |
| Screw Head Style | Modified Truss |
| Screw Point Style | Type 17 Point |
| Set Screw Thread Type | UNC |
| Compatible Groove Diameter | 0.31 Inches |
