RC-36 NC/NO Magnetic Reed Switch Recessed Wired Door Window Alarm, Magneti Door Switch, Contact Sensor, for Home Security and Burglar Alarm Systems, Sets of 10, (Brown)
Product details
| Management number | 211193969 | Release Date | 2026/04/04 | List Price | $14.00 | Model Number | 211193969 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Product DescriptionName：RC-36 NC/NO Magnetic Reed Switch.Feature:Widely Used - This Recessed Door Contact Sensor works with any access control or burglar alarm system available.Note - the Magnetic Door Switch must be installed according to the sensing distance. It can only provide a switch signal to the transmitter. It cannot directly load the power, nor directly connect the lamp!Specification:Model : RC-36.Material: ABS.Rated power: 10W.Rated current: 500(mA).Rated voltage: (VDC) 100.Mounting Type: Recessed.Anti-fire ABS shield Connecting mode: NC/NO.Operating distance: more than 15mm, less than 25mm.Switch Type: NO(normal open type), NO means Normally Open: when the magnet separate, the circuit is not conductive( light on ); When the magnet together, the circuit is conductive ( light ooff ).Package Includes: 10 Sets x RC-36 Magnetic Door Window Contact SensorWarm Tip:Due to manual measurement, there may be a slight error in size.【Worry-free Warranty】:With our 90-day money-back risk-free purchase guarantee, order now! If you are not satisfied in any way, any quality problem can be
- 【Product Name】:RC-36 NC/NO Magnetic Door Swith.
- 【Specification】: Rated Voltage: 100V;Contact Capacity: 500(mA) (Maximum Switch Current), Rated Power: 10W(Maximum Switch Power); Contact Type: NC/NO/COM,Trigger Range: 15-25mm.
- 【Normally Open Normally Closed】: Use Normally Open or Normally Closed freely, Cable definition: Gray for NC, Red for NO, White for common . Cable Length : 34cm/13.4", Overall Size: 23.2 x 22.8 mm / 2.2" x 0.91" x 0.89"(D*L).
- 【Application】: Magnetic door contact reed switch great for door alarm sensor, alarm, LED Switch, Relay, GPS low voltage devices...etc., Effective for Theft Deterrence. Yes ideal wooden door or window use.
- 【Package】: 10 Sets x Magnetic door contact reed switch, Here with our 90-day money back risk-free purchase guarantee,› See more product details › See more product details
| UPC | 733371461209 |
|---|---|
| Brand | priaolker |
| Color | White |
| Voltage | 100 Volts |
| Alert Type | Motion |
| Unit Count | 10.0 Count |
| Item Weight | 0.22 Kilograms |
| Manufacturer | priaolker |
| Model Number | RC-36 NC/NO Brown |
| Power Source | dc |
| BuiltIn Media | Bag |
| Connector Type | RJ45 |
| Control Method | Touch |
| Item Type Name | NC/NO |
| Item Dimensions | 1.18 x 0.59 x 0.98 inches |
| Mfr Part Number | RC-36 NC/NO |
| Antenna Location | Home Security |
| Sensor Technology | Wired Proximity |
| Compatible Devices | [Not Specifically Listed] |
| Installation Method | Wall Mount |
| Connectivity Technology | Wired |
| Assembly Instructions Description | Yes |
| Manufacturer Warranty Description | 90 days |
