Super Micro Supermicro X9DRW-3F Server Motherboard - Intel Chipset - Socket R LGA-2011 - Proprietary Form Factor - 512 GB DDR3 SDRAM Maximum RAM - DDR3-1600/PC3-12800, DDR3-1333/PC3-10600, DDR3-1066/PC3-8500, DDR3-800/PC3-6400 - RDIMM, UDIMM - 16 x Memor
Product details
| Management number | 205888956 | Release Date | 2025/11/02 | List Price | $194.40 | Model Number | 205888956 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Supermicro X9DRW-3F Server Motherboard - Intel Chipset - Socket R LGA-2011 - Proprietary Form Factor - 512 GB DDR3 SDRAM Maximum RAM - DDR3-1600/PC3-12800, DDR3-1333/PC3-10600, DDR3-1066/PC3-8500, DDR3-800/PC3-6400 - RDIMM, UDIMM - 16 x Memory Slots - Gigabit Ethernet - 6 x SATA Interfaces
Supermicro's New Generation X9 Serverboards offer the highest levels of performance, efficiency and scalability in the industry. The Supermicro X9 Serverboards are available in a variety of architectures including Twin and new Fat Twin, GPU Supercomputer, Data Center Optimized, SuperServer Advantage, I/O Optimized, SuperWorkstation, and SuperStorage Solutions. These Serverboards offers numerous advantages including up to 768GB of Reg. ECC DDR3-1600MHz memory in 24 DIMM slots, SATA 3.0 and SAS 2.0 (6Gb/s) HDD support, ConnectX FDR/QDR InfiniBand ports, dual 10 Gigabit Ethernet, Quad Ethernet LAN, PCI-E 3.0 technology, LSI 2308 controller with software RAID and LSI 2208 controller with hardware RAID, IPMI 2.0, and Intel Xeon processor E5-2600/1600 family for highest performance. With this New Generation X9 Serverboard Platform Supermicro offers the most extensive selection of solutions for Data Center, Enterprise IT, Cloud Computing, Graphics, Technical Computing, and HPC environments.
| Gigabit Ethernet | Yes |
| Power Supply Supported | EPS12V |
| Limited Warranty | 3 Year |
| Number of Total Expansion Slots | 1 |
| PCI Express Standard | PCI Express 3.0 |
| Total Number of PCI Express Slots | 1 |
| Form Factor | Proprietary Form Factor |
| Width | 13" (330.20 mm) |
| Depth | 12" (304.80 mm) |
| Graphics Controller Manufacturer | Matrox |
| Graphics Controller Model | G200 |
| Onboard Video | On-board Video Chipset |
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS-6 |
| RoHS |
| Number of SATA Interfaces | 6 |
| Number of SAS Interfaces | 8 |
| Total Number of Onboard USB Ports | 2 |
| Number of Onboard USB 2.0 Ports | 2 |
| Onboard LEDs Header | Yes |
| Onboard Serial Header | Yes |
| Maximum Memory Supported | 512 GB |
| Memory Technology | DDR3 SDRAM |
| Memory Standard | DDR3-800/PC3-6400 |
| DDR3-1600/PC3-12800 | |
| DDR3-1333/PC3-10600 | |
| DDR3-1066/PC3-8500 | |
| Number of Memory Slots | 16 |
| Memory Form Factor | RDIMM |
| UDIMM | |
| Memory Speed Supported | 1066 MHz |
| 1333 MHz | |
| 1600 MHz | |
| 800 MHz |
| Processor Supported | Xeon |
| Total Processor Supported | 2 |
| Processor Socket | Socket R LGA-2011 |
| 64-bit Processing | Yes |
| Chipset Manufacturer | Intel |
| QuickPath Interconnect | 8 GT/s |
| Product Type | Server Motherboard |
| Manufacturer Part Number | MBD-X9DRW-3F-O |
| Manufacturer Website Address | http://www.supermicro.com |
| Manufacturer | Supermicro Computer, Inc |
| Product Model | X9DRW-3F |
| Product Name | X9DRW-3F Server Motherboard |
| Package Type | Retail |
| Brand Name | Supermicro |
| RAID Levels | 5 |
| 1+0 | |
| 1 | |
| 0 | |
| Controller Type | Serial ATA/600 |
| Serial ATA/300 | |
| 6Gb/s SAS | |
| RAID Supported | Yes |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 3 |
| Network (RJ-45) | Yes |
| Audio Line In | No |
| Audio Line Out | No |
| Serial Port | Yes |
| Microphone Port | No |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 4 |
